Fiber Creasing Matrix for Die-Cutting Machine

Basic Info

Model NO.	0.8-3.0
Specification	50pcs/box, 10 box/carton
Trademark	shengtong
Origin	China
HS Code	39169090
Production Capacity	50000 PCS Per Week

Product Description

1.World's most advanced creasing matrix made from pressboard with average pinching times from60,000-100,000
2.Accurate locator ensure perfect registration.
3.Low profile chamfer board flows freely over the matrix,board marking is reduced
4.Finger lift adhensive tape backing paper easily and quickly removed.
5New and strong adhensive removes cleanly from the plate after use,will not move about during die cutting jobs.
6.Special sizes available to suit all board types.off-center and multi-crease from close creasing rule
7.It is extremely durable and accurate and provides benefits in time and cost.
8.Competitive price with high quality.
9.Off center and double matrix and matrix on reels are avilable upong demands

Color:white;yellow;green;gray
Size:0.3mm*0.8mm
Founction:to make creasing for boxs and cartons on the die-cutting machine
Application type:Durable and suitable for long-run die-cutting oper
Pressing times:more than 50,000
All kinds of special specifications can be customized models.
You can dhoose from a variety of standard models:
0.3*0.8 0.3*1.0 0.3*1.2 0.3*1.4
0.4*0.8 0.4*1.0 0.4*1.2 0.4*1.3 0.4*1.4 0.4*1.5
0.5*1.0 0.5*1.2 0.5*1.3 0.5*1.4 0.5*1.5 0.5*1.6
0.6*1.5 0.6*1.6 0.6*1.8 0.6*1.9 0.6*2.1
0.7*1.5 0.7*1.6 0.7*1.7 0.7*1.8 0.7*1.9 0.7*2.1 0.7*2.3 0.7*2.5 0.7*2.7 0.7*3.0
0.8*2.1 0.8*2.3 0.8*2.5 0.8*2.7 0.8*3.0 0.8*3.2 0.8*3.5 0.8*4.0 0.8*4.5 0.8*5.0 0.8*6.0
1.0*3.0 1.0*3.2 1.0*3.5 1.0*4.0 1.0*5.0 1.0*6.0
1.2*3.5 1.2*4.0 1.2*5.0 1.2*6.0
Cardboard choose contrast table

paper grams(g)	paper thickness(mm)	the height of the creasing line(mm)						common domestic creasing line
		23.50 23.40 23.30 23.20 23.10 23.00 23.24 22.90
200	0.28	0.3*1.0	0.4*1.0					0.5*1.0
250	0.35	0.3*1.2	0.4*1.2	0.5*1.2				0.5*1.2
300	0.42	0.3*1.3	0.4*1.3	0.5*1.4				0.5*1.4
350	0.50		0.4*1.4	0.5*1.5	0.6*1.5			0.5*1.5
400	0.56			0.5*1.6	0.6*1.6			0.5*1.6	0.8*1.6
450	0.63			0.5*1.7	0.6*1.7	0.7*1.7			0.8*1.7
500	0.70					0.71.7	0.8*1.7		0.8*1.7

corrugated paper	after flattened corrugated thickness	the height of the creasing line	the choosable creasing mould(1.05 thickness creasing line)	the choosable creasing mould(1.42 thickness creasing line)
E-Flute	0.65mm	23.10mm	0.7*2.3	----
E-Flute	0.75mm	23.00mm	0.8*2.5	----
B-Flute	0.85mm	22.90mm	0.8*2.7	0.8*3.2
C-Flute	0.95mm	22.80mm	1.0*3.0	1.0*3.5
C-Flute	1.05mm	22.70mm	1.0*3.2	1.0*3.5
	1.15mm	22.60mm	----	1.0*4.0
